Portable Anchor Cable Tensioner
The Portable Anchor Cable Tensioner is a manual tool designed for small, confined spaces and jobs that require frequent relocation.
Compact Tool For Confined Spaces And Quick Moves
The Portable Anchor Cable Tensioner is a manual tool designed for small, confined spaces and jobs that require frequent relocation. It does not need electricity or compressed air. This product works anywhere, regardless of power or air availability underground. Despite its compact size, it delivers up to 700 kN of tension force. This is sufficient for all standard roadway anchor support requirements.
Lightweight Construction Reduces Physical Strain
Our manual jack uses aerospace-grade materials and processes. The MS22-400/63 model weighs only 20 kg. This Portable Anchor Cable Tensioner is 20-30% lighter than competitive products. One worker can easily carry it to the worksite. This reduces labor intensity and embodies our mission to "improve labor quality." The tool anchor in our portable unit also lasts longer than standard parts. We optimized the materials and heat treatment process. This means fewer replacements, saving you money and reducing downtime.
Complete Technical Specifications
|
Model |
Rated Tension Force (KN) |
Cable Diameter (mm) |
Stroke (mm) |
Center Hole (mm) |
Jack Weight (Kg) |
Rated Oil Pressure (MPa) |
Handle Force (N) |
High Pressure Flow (ml/stroke) |
Low Pressure Flow (ml/stroke) |
Tank Capacity (L) |
Pump Weight (Kg) |
|
MS15-200/63 |
200 |
15.24 |
125 |
18 |
15 |
63 |
350 |
2.3 |
14.5 |
2.0 |
10.0 |
|
MS18-300/63 |
300 |
17.8 |
100 |
20.5 |
18 |
63 |
350 |
2.3 |
14.5 |
2.0 |
10.0 |
|
MS19-300/63 |
300 |
18.9 |
100 |
21.5 |
18 |
63 |
350 |
2.3 |
14.5 |
2.0 |
10.0 |
|
MS22-400/63 |
400 |
21.8 |
100 |
25 |
20 |
63 |
350 |
2.3 |
14.5 |
2.0 |
10.0 |
|
MS22-500/63 |
500 |
21.8 |
100 |
25 |
24 |
63 |
350 |
2.3 |
14.5 |
2.0 |
10.0 |
|
MS29-600/63 |
600 |
28.6 |
100 |
32 |
26 |
63 |
350 |
2.3 |
14.5 |
2.0 |
10.0 |
|
MS32-600/63 |
600 |
32 |
100 |
35 |
26 |
63 |
350 |
2.3 |
14.5 |
2.0 |
10.0 |
|
MS35-700/63 |
700 |
35 |
100 |
39 |
29 |
63 |
350 |
2.3 |
14.5 |
2.0 |
10.0 |
Customization and Shipping Information
We customize the jack height and dimensions based on your workspace. We also offer different stroke lengths, cable specifications, and power source combinations. For special lightweight needs, we use high-strength alloys. All Portable Anchor Cable Tensioner units ship in solid wood cases with quick-release stainless steel buckles. Each component is wrapped separately in bubble film. Cases are clearly marked with product info and warnings. We support FOB, EXW, CIF and help with customs documents.
